The biochemical structure of proteins and peptides determines their biological functions. There are many indications that even minute structural or spatial changes can promote the development of diseases. Many neurodegenerative diseases have been attributed to misfolding of proteins and peptides that is caused by such changes. Amyloid beta (Aβ42) peptides play a key role in Alzheimer’s disease; they differ in a single amino acid residue and represent hereditary mutants of Alzheimer’s disease.

Until now there has not been a simple and accurate method for predicting mutations in proteins. At KIT’s Institute of Functional Interfaces (IFG), a research group led by Professor Jörg Lahann has developed a method for detecting misfolding via the structure of dried protein and peptide solutions.

“The stain patterns were not only characteristic and reproducible but also result in a classification of eight mutations with a predictive accuracy of more than 99 percent,” says Lahann, author of the study, in describing the results. The group showed that crucial information about the primary and secondary structures of peptides can be gleaned from the stains left behind by drying droplets of peptide solution on a solid surface.

Stain Patterns as Exact Peptide Fingerprints

The protein and peptide solutions are precisely placed on glass slides by an automated pipetting system to ensure controlled and reproducible results. The surfaces of the slides were prepared in advance with a hydrophobic polymer coating.

To analyze the complex stain patterns from the dried droplets, the researchers acquired images using polarization microscopy. The images were then analyzed with deep-learning neural networks.

“Since the structures are very similar and difficult to distinguish with the naked eye, it was definitely a surprise that the neural networks were so effective,” says Lahann about the results. “The stain patterns of amyloid beta peptides serve as exact fingerprints that reflect the structural and spatial identity of a peptide.”

 This technology enables the identification of Alzheimer variants with maximum resolution within a few minutes, according to Lahann.

Sample Preparation Delivers Fast Diagnoses

The results suggest that a method as simple as drying a droplet of peptide solution on a solid surface can serve as an indicator for minute differences in the primary and secondary structures of peptides.

“Scalable and accurate detection methods for the stratification of conformational and structural protein alterations are urgently needed in order to decode the pathological signatures of diseases like Alzheimer’s and Parkinson’s,” says Lahann. It is also a relatively simple method that requires no elaborate preparation of samples and thus enables simple and patient-friendly diagnosis.

Furthermore, the method has great potential for other applications in medical diagnostics and in the molecular detection of diseases. (sfo)

Featured image: Neural networks can detect minute differences in the stain patterns from dried peptide solutions (left: amyloid beta (Aβ42) peptide; right: mutation). Photo: KIT
